Inspection and Factory Testing Services | Children's Furniture Inspection Standards and Methods

1. Appearance quality inspection standards

1. Wood component inspection

• Material requirements:

  • No through cracks (length > 50mm will be rejected)

  • Decay area ≤ 20% (inner surface)

  • Section diameter ≤ 12mm (except for special designs)

• Defect handling:

  • Allowable repair defects ≤ 4 (external surface)

  • Color difference of repair materials ≤1 level (GB/T 250)

  • Worm-eaten holes must be filled and reinforced

2. Inspection of wood-based panel components

• Surface quality:

  • Dry and wet flower area ≤5% (inner surface)

  • Scratch length ≤ 30mm (depth ≤ 0.1mm)

  • Color difference ΔE≤1.5 (measured by spectrophotometer)

• Structural requirements:

  • Edge peel strength ≥100N/cm

  • Plate warping ≤3mm/m

  • Hole position deviation ≤0.5mm

3. Metal accessories inspection

• Surface treatment:

  • Electroplating layer thickness ≥8μm (X-ray fluorescence method)

  • Salt spray test ≥48 hours (ISO 9227)

  • Coating adhesion ≥3B (cross-hatch method)

• Structural safety:

  • Exposed thread chamfer ≥0.5mm

  • Tensile strength of welding point ≥300N

  • Hinge life ≥ 20,000 times

2. Structural safety inspection standards

1. Edge and tip protection

• Chamfer specifications:

  • External angle R ≥ 10mm or arc length ≥ 15mm

  • Internal angle R≥2mm

  • Contactable edge chamfer ≥0.5mm

• Protrusion protection:

  • If the protruding length is greater than 10mm, a protective cover is required.

  • The protective cover does not fall off when the pulling force is ≥90N

  • The ends of tubular parts must be closed

2. Hole clearance requirements

• Safety distance:

  • 5mm＜Aperture＜12mm (anti-pinch finger)

  • Clearance between moving parts <6mm or >12mm

  • Guardrail spacing 60-75mm (anti-stuck head)

3. Stability testing

• Overturning test:

  • Tilt 10° without overturning

  • Stable with a load of 50kg and a tilt of 15°

  • The drawer can be fully opened and loaded with 20kg without tipping over

3. Environmental performance testing standards

1. Limits of Hazardous Substances

• Formaldehyde release:

  • ≤0.05mg/m³ (climate chamber method)

  • ≤1.5mg/L (perforation method)

• VOC control:

  • Benzene ≤ 0.05 mg/m³

  • TVOC≤0.25mg/m³

2. Heavy metal content

• Surface coating:

  • Lead ≤ 60 mg/kg

  • Cadmium ≤40 mg/kg

  • Chromium ≤40mg/kg

• Substrate testing:

  • Mercury ≤ 5 mg/kg

  • Arsenic ≤ 10 mg/kg

4. Mechanical properties test

1. Durability testing

• Seat type:

  • 10,000 seat impacts

  • 5000 handrail loads

  • 2000 times backrest fatigue

• Storage:

  • Drawer push and pull 10,000 times

  • Cabinet door opened and closed 5000 times

  • Shelf 100kg static load 24h

2. Strength test

• Connection parts:

  • Screw torque ≥1.5N·m

  • Mortise and tenon joint strength ≥800N

  • Bonding strength ≥2.5MPa

• Special parts:

  • Guardrail vertical load ≥1000N

  • Pedal impact ≥50J

  • Folding mechanism life ≥ 5000 times

5. Functional testing

1. Performance

• Moving Parts:

  • Drawer slide noise ≤45dB

  • Hinge opening angle ≥95°

  • Swivel chair rotation resistance 0.5-2N·m

• Adjustment mechanism:

  • Height adjustment force ≤ 50N

  • Tilt adjustment lock is reliable

  • Telescopic mechanism without jamming

2. Safety devices

• Anti-pinch design:

  • Closing speed ≤0.5m/s

  • Buffer distance ≥30mm

  • Induction pressure ≤5N

• Warning signs:

  • Permanent safety signs

  • Instructions for use

  • Warning label durable

6. Packaging and transportation inspection

1. Packaging specifications

• Protection requirements:

  • Corner protection thickness ≥5mm

  • Moisture-proof membrane sealing

  • Seismic material density ≥ 25kg/m³

• Marking system:

  • Stacking limit mark

  • Center of gravity position mark

  • QR code traceability

2. Transportation testing

• Drop test:

  • Falling from corner/edge/surface (80cm high)

  • Vibration test 3h (5-200Hz)

  • Inclined impact test

Implementation of this specification must comply with the latest requirements of GB 28007-2011, "General Technical Requirements for Children's Furniture." Manufacturers are advised to establish a digital quality traceability system and maintain video records of key processes. Exported products must also comply with standards such as EU EN 71 and US ASTM F963. Smart children's furniture must also undergo electromagnetic compatibility (EMC) and wireless communication (RF) certification testing.
